When choosing whether to use a color or black-and-white camera in a measurement solution, it is first necessary to identify the main differences between color and black-and-white cameras and make a choice based on the specific needs of the measurement task.

Differences between color and black and white cameras

Imaging Principles

Color camera: Through techniques such as the color space difference method or Bayer filters, the three basic colors of red, green and blue in light are separated and sensitized separately to produce color images. This imaging method has advantages in restoring the color information of objects, but it may introduce the low-pass effect brought about by color interpolation, which affects the clarity of the image.

Black-and-white camera: directly sensitizes the light and does not differentiate between colors, so the image generated is in grayscale. Black-and-white cameras do not have the interference of color interpolation in the imaging process, and usually have higher resolution, response sensitivity and signal-to-noise ratio, and a smaller amount of image data for easy processing.

Application Scenarios

Color Camera: Suitable for application scenarios that require color detection or recognition, such as product color classification, color defect detection in quality inspection, etc.

Black and white camera: Suitable for application scenarios that are not sensitive to color or only need to extract edge information, such as size measurement, edge detection, shape recognition and so on.

When selecting a camera for a measurement program, you need to consider the actual measurement task requirements, measurement accuracy and efficiency. This is described in detail below:

Requirements for the measurement task

①: If the measurement task requires identification or detection of the color of the object to be measured, a color camera should be selected.

②: If the measurement task mainly focuses on the gray-scale information of the image, such as size, shape, edges, etc., and is not sensitive to color, a black-and-white camera should be selected.

Measurement accuracy and efficiency:

①: Black-and-white cameras usually have higher resolution, response sensitivity, and signal-to-noise ratio in equivalent comparisons, and therefore may provide higher accuracy and efficiency in certain measurement tasks.

②: However, color cameras are indispensable for measurement tasks that require color information.
