As a core component of machine vision systems, the selection of industrial cameras directly impacts inspection accuracy, efficiency, and stability. However, due to a lack of experience or cognitive biases, many users often fall into the following common pitfalls during the selection process, resulting in mismatched equipment performance or wasted resources.

Misconception 1: Blindly pursuing high resolution

• Misconception: The higher the resolution, the sharper the image and the better the inspection results.

•

  Fact: High resolution significantly increases data volume, leading to slower processing speeds and placing higher demands on lenses, lighting, and storage devices. The required resolution should be calculated based on the smallest feature size of the inspection target (such as defect width) to avoid over-specifying the system.



Misconception 2: Neglecting to choose the right sensor type

• Misconception: All sensors (CCD/CMOS) perform the same, so there is no need to distinguish between them.

•

  Fact : CCD: High sensitivity and low noise, suitable for low-light or high-speed scenarios, but high cost and high power consumption；CMOS: Low cost, high integration, and high frame rates, suitable for motion detection, but dark current noise may affect performance in low-light conditions.



Misconception 3: Frame rate is out of sync with actual needs

• Misconception: A higher frame rate is always better and works for all scenarios.

•

  Fact: A high frame rate comes at the expense of resolution or dynamic range and increases costs. The required frame rate should be calculated based on the inspection speed (e.g., production line cycle time).

Misconception 4: Ignoring interface type matching

• Misconception: All interfaces (GigE/USB 3.0/Camera Link) have the same performance.

•

  Fact : GigE: Supports long-distance transmission (100 m) and is suitable for distributed systems, but has lower bandwidth (1 Gbps)；USB 3.0: Plug-and-play, high bandwidth (5 Gbps), but short transmission distance (5 m)；Camera Link: Ultra-high bandwidth (25 Gbps), suitable for high-speed applications, but high cost and complex cabling.

Misconception 5: Dynamic range does not match the scene

• Misconception: The wider the dynamic range, the better the image quality.

•

  Fact: High Dynamic Range (HDR) cameras are suitable for scenes with high contrast between light and dark areas (such as welding inspection), but in evenly lit scenes, an excessively wide dynamic range may increase noise. The choice should be based on actual lighting conditions.

Misconception 6: Ignoring color accuracy requirements

• Misconception: Black-and-white cameras are inexpensive and can replace color cameras.

•

  Fact : Black-and-white cameras: High sensitivity, suitable for grayscale contrast detection (such as edge detection)；Color cameras: Essential when color features need to be identified (such as product classification or distinguishing defects by color).

Misconception 7: Failure to consider environmental adaptability

• Misconception: All cameras can withstand harsh environments.

• Fact: Industrial environments may involve high temperatures, humidity, vibration, or electromagnetic interference, so it is necessary to select cameras with appropriate protection ratings (such as IP67), vibration-resistant designs, or industrial-grade interfaces. For example, the food industry requires waterproof and corrosion-resistant cameras, while the automotive industry requires vibration-resistant cameras.

Misconception 8: Overreliance on supplier recommendations

• Misconception: The model recommended by the supplier is always the best fit.

•

  Fact: Suppliers may recommend products based on inventory or profit margins rather than actual needs. You need to clearly define your own specifications (resolution, frame rate, interfaces, etc.) and verify performance through testing.

Misconception 9: Ignoring software compatibility

• Misconception: Cameras are automatically compatible with vision software.

•

  Fact: Cameras from different manufacturers may require specific drivers or SDKs, so you need to verify whether the software supports your camera model (e.g., Halcon, VisionPro, etc.).

Misconception 10: Not leaving room for future upgrades

• Misconception: It is sufficient to meet current needs; there is no need to consider future expansion.

• Fact: When production lines are upgraded or inspection accuracy is improved, the camera may become a bottleneck. We recommend selecting models with some margin in resolution, frame rate, or interface capabilities, or cameras that support modular upgrades.
